PCB Assembly

Upload your BOM or request a quote today.

PCBA
Capabilities

File Requirements

PCB file

Quantity

BOM List

Assembly drawings for top and bottom payers with component IDs and orientation

Pick & Place file if automated machine placement is required

List of components for programming and programming data

Final inspection and test procedures

Feature	Capability
Quantity	No Minimun Order Quantity
	Prototype - Production
	Mass Production
Build Time	Quickturn (1-5 days), Standard (10 days) or scheduled deliveries
Assembly Types	Surface mount(SMT)
	Thro-hole
	Mixed technology (SMT & Thru-hole)
	Single or double sided placement
	Conformal coating
	Shield cover assembly for EMI emission control
Solder Type	Leaded
	Lead-free - RoHS
Parts Procurement	Full Turnkey
	Partial Turnkey
	Kitted/Consigned
Component types	SMT 01005 or larger
	BGA 0.35mm pitch, POP (Package on Package)
	WLCSP 0.35mm pitch
	Hard metric connectors
	Cable & wire
SMT Parts Presentation	Bulk
	Cut tape
	Partial reel
	Reel
	Tube
	Tray
Stencils	Laser-cut stainless steel
Other Techniques	Free DFM Review
	Box Build Assembly
	100% AOI test and X-ray test for BGA
	IC programming
	Components cost-down
	Function test as custom
	Protection technology

Assembly Service

To guarantee reliability, we source electronic components only from vetted, trusted distributors and manufacturers—and every component undergoes thorough verification of its specifications and quality before it reaches you.
